Torpatch
Torpatch is a data file generator for the Persistence of Vision
raytracer. Given a series of points in space, Torpatch joins them
smoothly with sections of tori. As a basic function Torpatch can output
the coordinates of a torus section passing through any three points, or
through two points given a tangent at one of them. The torus section can
be extended to pass smoothly through any other set of points. Torpatch can
also generate random 'tangles' if so desired.
This program has several uses:
- Making a smooth join between two POV primitives sometimes calls for a
torus section between them. Torpatch is ideal for obtaining the
coordinates of such a joining object.
- The ability to easily get the coordinates of the torus through any three
points is helpful in other circumstances such as modelling chains.
- Torpatch's true purpose, however, is the modelling of random coils and
'tangles', either predefined through a series of control points, or
completely random. The image on my gallery page
is a good example. Such tangles could be modelled using e.g.
Connect-the-Dots, but would require a much greater number of
primitives to look smooth and hence a much longer tracing time.
Torpatch is released under the GNU GPL.
Download Torpatch (DOS EXE)
Download Torpatch source (Turbo Pascal)
Download Torpatch source (C)
Yes, the C conversion is done! Sorry about the delay...
Torpatch was written by
Mark Mackey.
Email: mark@swallowtail.org
C conversion by Nathan Beddes.
Email: Nathan.Beddes@m.cc.utah.edu
